2

整機重量        overall weight

9600kg

3

斗容量          bucket capacity

1.8-2.5m3

4

最大牽引力      maximum traction force

95KN

5

最大掘起力      maximum breakout force

127KN

6

最大爬坡能力    maximum grade ability

30℃

7

最大卸載高度    maximum dump height

3100mm

8

最大卸載距離    maximum dump reach

966mm

9

整機外形尺寸    overall dimension (L×W×H)

6890*2430*3070mm

10

最小轉彎半徑    minimum turning radius

5097mm

發動機Engine

11

型號model

Deutz enginesWP6G125E22

12

型式type

直列、水冷、四沖程、直噴

     Vertical, in-line, water cooled, 4-stroke diesel engine

13

汽缸數-缸徑*行程N(yùn)O. of cylinder-bore*stroke

6-108*125

14

額定功率        rated power

92kw—2200r/min

15

最大扭矩        maximum torque

500N.m

16

最低燃油消耗率 min. fuel-consume ratio

≦210Kw/h

傳動系統

     Transmission system

17

變矩器型式      torque converter

YJ315-X

18

變速箱型式      gearbox mode

定軸常嚙合式

     Power shaft normally engaged straight gear

19

檔位數          gears

前進檔4個，倒退檔2個

     4 forward  2 reverse

20

最高車速        maximum speed

40km/h

驅動橋Drive axles

21

主減速式：    main reducing spiral

螺旋傘齒輪一級減速bevel gear grade 1reduction

22

輪邊減速型式    decelerating mode

一級行星減速

     Planetary reduction grade 1

23

軸距            wheel base (mm)

2740mm

24

輪距            wheel tread

1800mm

25

最小離地間隙    ground clearance

400mm

液壓系統

     Hydraulic system

26

系統工作壓力    system working pressure

16,5MPa

27

動臂提升時間    boom lifting time

4.83S

28

三項和          total time

9.15±0.5s

制動系統

     Brake system

31

行車制動        service brake

氣頂油鉗盤式四輪制動

     air assist disc brake on 4 wheels

32

駐車制動        parking brake

手動嵌盤式

     Manual disk brake

輪胎

     Tyre

33

規格            type specification

17.5-25

34

前輪氣壓        front tyre pressure

0.4Mpa

35

后輪氣壓        rear tyre pressure

0.35Mpa
